Heating pipe is in a seamless metal pipe (carbon steel pipe, titanium, stainless steel pipe, copper pipe) into the heating wire, gap filled with good thermal conductivity and insulation of magnesia powder and then shrink tube, then processed into various type of the user's needs. It has a simple structure, high thermal efficiency, good mechanical strength, the harsh environment with good adaptability. It can be used for all kinds of liquid and acid and alkali salt heating, but also to adapt to the low melting point metal heating melt (lead, zinc, tin, babbitt).

Electric heating tube is specially converts electrical energy into heat energy of electrical components, its price is cheap, easy to use, easy installation, no pollution, is widely used in all kinds of heating, the service life of electric heating tube is very long, the general design using.

Screw size	Voltage/power	Tube material	Tube diameter	Length
DN40	220V/3000W 380V/3000W	copper	8mm	210mm
DN40	220V/6000W 380V/6000W	copper	8mm	250mm
DN40	220V/9000W 380V/9000W	copper	8mm	300mm
DN40	380V/12000W	copper	8mm	350mm
DN40(lengthened)	380V/9000W	copper	8mm	600mm
DN40(lengthened)	380V/12000W	copper	8mm	600mm
DN50	220V/3000W 380V/3000W	copper	10mm	210mm
DN50	220V/6000W 380V/6000W	copper	10mm	250mm
DN50	220V/9000W 380V/9000W	copper	10mm	300mm
DN50	380V/12000W	copper	10mm	350mm
DN50(lengthened)	380V/9000W	copper	10mm	600mm
DN50(lengthened)	380V/12000W	copper	10mm	600mm
